Brand: Firefly
Collections:
$59.00 USD
$59.00 USD

Soc

Rockchip RK3562J

Quad-core 64-bit Cortex-A53 processor, up to 1.2GHz
Vpu

4K 30fps H.265/H.264/VP9 and 1080P 60fps H.264 video decoding

1080P 60fps H.264 video encoding

13M ISP with HDR
Ram

LPDDR4/LPDDR4x (2GB/4GB/8GB optional)
Storage

eMMC (16GB/32GB/16GB/32GB/64GB optional)
Power

DC 12V (5.5mm x 2.1mm, supporting 9V~36V wide input voltage)
Power consumption

Normal: 2.04W (12V/0.17A)

Max: 4.8W (12V/400mA)
Video output

1 x MIPI-DSI（2048 x 1080@60Hz）
Video input

2 x MIPI-CSI (1 x 4 Lanes or 2 x 2 Lanes)
Audio input

1 x MIC (2P-2mm), 1 x SPK (1.3W/8Ω, 2P-2mm)
Os

Ubuntu, Debian, Buildroot+QT
Dimension

146mm x 102mm x 21.5mm
Weight

≈120g
Environment

Operating temperature: -40℃- 85℃

Operating humidity : 5%～90%RH (non-condensing)
Network

1 x Gigabit Ethernet (1000 Mbps), 1 x 100 Mbps, 2.4GHz/5GHz dual-band WiFi (802.11a/b/g/n/ac), Bluetooth 5.0, and 4G LTE expansion (Mini PCIE)
Usb

1 x USB3.0 (OTG), 1 x USB2.0, 2 x USB2.0 HOST (Wafer connector)
Product tutorials Click Here
Sdk software and firmware files Click Here
