ITX-3568JQ Quad-core ITX Motherboard

$79.00 USD
$79.00 USD
Shipping calculated at checkout.
  • American Express
  • Apple Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Union Pay
  • Visa
Brand: Firefly
Collections:
FireflyAIO-3399PRO-JD4 Industrial Motherboard
AIO-3399PRO-JD4 Industrial Motherboard
AIO-3576C 6T AIOT Industrial Edge Computing Motherboard
Firefly StoreAIO-3576C 6T AIOT Industrial Edge Computing Motherboard
$79.00 USD
$79.00 USD

Soc

RK3568J,Up to 1.4GHz

Quad-core 64-bit Cortex-A55 processor, 22nm lithography process
Gpu

ARM G52 2EE , supporting OpenGL ES 1.1/2.0/3.2 , OpenCL 2.0 , Vulkan 1.1

A built-in high-performance 2D acceleration hardware
Npu

Integrated with an AI accelerator RKNN NPU, 1.0 Tops@INT8 (commercial), 512MAC NPU (industrial and automotive)

Support framework switching of Caffe/TensorFlow/TFLite/ONNX/PyTorch/Keras/Darknet
Vpu

4K@60fps H.265/H.264/VP9 video decoding (or 8-channel 1080P 30fps multi-format decoding)

1080P@60fps H.265/H.264 video encoding
Ram

LPDDR4 (1GB/2GB/4GB/8GB)
Storage

eMMC (8GB/16GB/32GB/64GB/128GB optional), 16 MB SPI Flash
Pcie

1 × PCIe 3.0 (2 lanes), capable of extending to standard PCIe 3.0 device.
Sata

1 × SATA 3.0 standard interface

1 × M.2 SATA 3.0 (2242 SATA SSD expansion)
Power

Power supply ways:

DC 12V input (DC 5.5×2.1mm, 12V/1.5A or higher recommended)

Computer case with 12V input (standard ATX power interface)

POE 48V power input (up to 60W)
Display

1 × HDMI 2.0, supporting 4K@60 Hz

1 × MIPI DSI, supporting single-channel 1920 * 1080@60fps

1 × LVDS display interface (via pin headers)

2 × VGA (1080P)

* Support up to three displays
Camera

1 × MIPI CSI (capable of configuring a single-channel (4 lanes) or a dual-channel (2 lanes))
Audio

1 × HDMI audio output

1 × 3.5mm headphone audio output

1 × Speaker output (10W-8Ω class D)
Os

Support Android 11.0, Ubuntu 18.04, Ubuntu 20.04, and RTLinux
Dimension

17cm×17cm (standard Mini-ITX), compatible with standard ITX computer cases
Weight

≈ 400g (without peripherals)
Environment

Temperature: -40℃ ~ 85℃

Humidity: 10%～90%RH (non-condensing)
Usb

4 × USB 3.0 (current limiting: 1A)

4 × USB 2.0 (three of them via the mainboard’s pin header) (current limiting: 500mA)
Other

RS485, RS232, I2C, CAN, UART, ADC, GPIO, Debug, FAN, MIC
Product tutorials Click Here
Sdk software and firmware files Click Here
